Yuankong Energy Storage & Charging adopts an integrated architecture consisting of core equipment, intelligent management system and supporting facilities. It covers maglev flywheel energy storage units, charge-discharge converter systems, maglev bearing control systems, vacuum maintenance systems, station-level energy management systems, optional electrochemical energy storage, as well as supporting facilities including booster stations and electric control buildings, forming a complete frequency regulation energy storage system.

Core Energy Storage UnitMaglev flywheel energy storage devices with matched power and capacity (models including 1.25MW/125kWh, 4MW/125kWh, etc.) and electrochemical energy storage systems are deployed according to frequency regulation demands.

Control & Management UnitThe station-level Energy Management System (EMS) delivers all-round management over grid connection, PCS, FMS, booster stations, environmental monitoring and fire alarm. It supports primary frequency regulation simulation, real-time operational calculation control and parameter monitoring.

Supporting FacilitiesBooster stations, electric control buildings and comprehensive buildings ensure stable system operation.

Flywheel energy storage acts as a sprinter with strong explosive power. Electrochemical energy storage is like a long-distance runner featuring great endurance and large capacity. Their combination enables both short-term and long-term response capabilities.
